The Icon-5 OP is a smart, laser-based 5-part differential hematology analyzer with an open vial sampling option.
The Icon-5 OP is a smart, laser-based 5-part differential hematology analyzer with an open vial sampling option.
The Icon-5 OP is a smart, laser-based 5-part differential hematology analyzer with an open vial sampling option that inherited its predecessors' elegant and award-winning design. The Icon-5 OP provides a 27-parameter complete blood cell count report that includes a 5-part diff WBC scattergram, as well as RBC and PLT histograms, using the following measurement technologies: laser-based forward-scattered light method for the differentiation of white blood cells (WBC), volumetric impedance method for detection of red blood cells (RBC) and photometric method for the measurement of hemoglobin (HGB) levels.
The Icon-5 OP was primarily developed to be used in Point-of-Care (PoC) environments, such as in Intensive Care Units, Emergency Departments, GP Offices, Blood Banks, or even Mobile Care Units, because it has not only a compact size, low reagent consumption, and small sampling volume processing, but it also doesn’t require any weekly maintenance action from the user.
| Parameters (27) | WBC, LYM, MON, NEU, EOS, BAS, LYM%, MON%, NEU%, EOS% BAS%, NLR, RBC, HGB, HCT, MCV, RDWsd/cv, MCH, MCHC, PLT, MPV, PCT, PDWsd/cv, PLC-R%, PLC-C |
| Measurement Technology | Laser-based forward-scattered light detection for WBC Volumetric impedance method for RBC Photometric method for HGB |
| Scattergram | WBC 5-part |
| Histograms | RBC, PLT |
| Sampling mode | Open vial sampling |
| Sample volume Aspirated Processed | 38 uL whole blood 2* 1.4 uL whole blood |
| Throughput | 57 tests per hour |
| Precision (CV, max) | WBC: 3%, RBC: 2%, MCV: 1%, HGB: 2%, PLT: 5% |
| Storage capacity | 40,000 (max.) test results including scattergrams, histograms, and patient data |
| User interface | 10.1” LCD with capacitive touchscreen Resolution: 800×1280 (portrait) |
| Languages | English, Italian, French, Russian, Hungarian, Spanish, Romanian, Portuguese, Vietnamese, Ukrainian, Bosnian |
| Connectivity | 2 x USB ports, Ethernet, LIS (HL7 and ASTM) |
| Dimensions (HxWxD) | 280 x 216 x 336 mm |
| Net weight | 8.5 kg |
| Power | External power supply, 12 VDC, 5A (100-240 VAC 50-60 Hz) |
| Power Consumption | Maximum 60W |
| Reagents | Norma-iDil5 OP, Norma-iLyse5 OP, Norma-iClean5 OP |
